Optional equipment
1)Auto loader 2)corona treatment 3)air compressor 4)rotating die head 5)Fast type screen changer 6)double back to back winder 7)air shaft
Main parameter
| Model | SJ-ABA-1300 | SJ-ABA-1600 | SJ-ABA-2200 |
| Suitable materials | HDPE,LLDPE.LDPE | HDPE,LLDPE.LDPE | HDPE,LLDPE,HDPE |
| Film width | 600-1200mm | 1000-1500mm | 1500-2000mm |
| Film thickness | 0.02-0.020mm | 0..02-0.020mm | 0..02-0.020mm |
| Output | 160kg/h | 180kg/h | 220kg/h |
| Extrusion unit | |||
| Screw diameter | Φ55*2 | Φ60*1&Φ65*1 | Φ75*1&Φ65*1 |
| Screw L/D | 30:1/32:1 | 30:1/32:1 | 30:1/32:1 |
| Screw material | Sacm-645/38Crmoala | Sacm-645/38Crmoala | Sacm-645/38Crmoala |
| Bareeal material | Sacm-645/38Crmoala | Sacm-645/38Crmoala | Sacm-645/38Crmoala |
| Barrel cooling fan | 550w*6 | 550w*7 | 550w*8 |
| Main motor | 18.5kw*2 | 22kw*1&30kw*1 | 30kw*1&37kw*1 |
| Barral temperature control | 3zone*2 | 3zone*2 | 4zone*2 |
| Average power cosume | 45kw | 60kw | 85kw |
| Die head unit | |||
| Die head | Φ250mm | Φ320mm | Φ400mm |
| Temperatire control | 10zones | 12zones | 12zones |
| Air ring | dual type air ring | dual type air ring | dual type air ring |
| Air blower | 7.5kw | 11kw | 11kw |
| Take up unit | |||
| Roller width | 1300mm | 1600mm | 2200mm |
| Effective width | 1200mm | 1500mm | 2000mm |
| Take-up speed | 10-120m/min | 10-120/min | 10-120m/min |
| Take-up motor | 1.5kw | 2.2kw | 3.7kw |
| Winding unit | |||
| Winding type | surface friction type
|
surface friction type
|
surface friction type
|
| Winding speed | 10-120m/min | 10-120m/min | 10-120m/min |
| Voltage | 380v,50hz,3phase | 380v,50hz,3phase | 380v,50hz,3phase |
| Machine weight | 4T | 5.5T | 7.5T |
| Machine size | 6*3.5*6.5M | 6*4*7.5M | 7*4.5*9.5M |
