Optional equipment
-
- Auto loader
- corona treatment
- air compressor
- rotating die head
- Fast type screen changer
- double back to back winder
- air shaft
Main parameter
| Model | SD-L55-1100 | SD-L60-1300 | SD-L65-1600 |
| Suitable materials | HDPE,LLDPE.LDPE | HDPE,LLDPE.LDPE | HDPE,LLDPE,HDPE |
| Film width | 500-1000mm | 600-1200mm | 1000-1500mm |
| Film thickness | 0.01-0.015mm | 0.01-0.015mm | 0.01-0.015mm |
| Output | 120-150kg/h | 150-180kg/h | 190-220kg/h |
| Extrusion unit | |||
| Screw diameter | Φ55 | Φ60 | Φ65 |
| Screw L/D | 32:1 high speed screw | 32:1 high speed screw | 32:1 high speed screw |
| Screw material | Sacm-645/38Crmoala | Sacm-645/38Crmoala | Sacm-645/38Crmoala |
| Bareeal material | Sacm-645/38Crmoala | Sacm-645/38Crmoala | Sacm-645/38Crmoala |
| Barrel cooling fan | 370w*3 | 370w*3 | 370w*4 |
| Main motor | 22kw | 30kw | 37kw |
| Barral temperature control | 4zone | 4zone | 4zone |
| Average power cosume | 25kw | 35kw | 60kw |
| Die head unit | |||
| Die head | Φ220 | Φ250 | Φ320 |
| Temperatire control | 7zones | 8zones | 8zones |
| Air ring | dual type air ring | dual type air ring | dual type air ring |
| Air blower | 7.5kw | 11kw | 11kw |
| Take up unit | |||
| Roller width | 1100mm | 1300mm | 1600mm |
| Effective width | 1000mm | 1200mm | 1500mm |
| Take-up speed | 10-120m/min | 10-120/min | 10-120m/min |
| Take-up motor | 1.5kw | 1.5kw | 2.2kw |
| Winding unit | |||
| Winding type | surface friction type
(PLC Automatic changing system） |
surface friction type
(PLC Automatic changing system） |
surface friction type
(PLC Automatic changing system） |
| Winding speed | 10-120m/min | 10-120m/min | 10-120m/min |
| Voltage | 380v,50hz,3phase | 380v,50hz,3phase | 380v,50hz,3phase |
| Machine weight | 3.5T | 4.5T | 5T |
| Machine size | 6.5*3.2*6.8M | 7*3.5*7M | 7*4*7.5M |
