Optional equipment
1)Auto loader 2)corona treatment 3)air compressor 4)rotating die head 5)Fast type screen changer 6)double back to back winder 7)air shaft
Main parameter
| Model | SJ-A45/600 |
| Suitable materials | HDPE,LLDPE.LDPE |
| Film width | 100-500 |
| Film thickness | 0.005-0.10mm |
| Output | 40kg/h |
| Extrusion unit | |
| Screw diameter | Φ45 |
| Screw L/D | 28:1 |
| Screw material | Sacm-645/38Crmoala |
| Bareeal material | Sacm-645/38Crmoala |
| Barrel cooling fan | 220w |
| Main motor | 7.5kw |
| Barral temperature control | 2zone |
| Average power cosume | 10kw |
| Die head unit | |
| Die head | Φ40mm |
| Temperatire control | 2zones |
| Air ring | normal type air ring |
| Air blower | 0.75kw |
| Take up unit | |
| Roller width | 600mm |
| Effective width | 500mm |
| Take-up speed | 10-80m/min |
| Take-up motor | 1.1kw |
| Winding unit | |
| Winding type | surface friction type
|
| Winding speed | 10-60m/min |
| Voltage | 380v,50hz,3phase |
| Machine weight | 1.6T |
| Machine size | 2.2*2*2.3M |
