Brief introduction
The non-glue paper straw is a new type of straw formed by the principle of paper thermoforming. It is a new product that is improved based on the glue smell caused by the existing glue bonding, poor taste experience, poor waterproof performance, and low temperature resistance.Pre-coated products can effectively improve such problems. We always aim to improve the consumer experience.
Main Technical Parameters
| Raw material | single/double PE coated paper,non-plastic coated paper,PLA coated paper |
| Number of roller | 2-4 layer |
| Tube diameter | 4-12mm |
| Tube wall-thickness | 0.5-1 mm |
| Cutting Length | 110mm-length between two cutting knife |
| Winding head | 2 head/1 belt |
| Total Power | 13kw |
| Cutter | 7 sets pneumatic driving by servo control |
| Operator | 1-2 person |
| Winding speed | 0-50 m/min |
| Speed control | Frequency |
| Working Air Pressure | 0.3-0.5Mpa,0.4M3/min |
| Power Supply | 380V/3Phase/50Hz |
| Measurement | 5600*1600*1750mm |
| Working Space | 11000mm * 6000mm*1900mm |
| Weight | 1500kgs |
Specifications
| Suitable for small diameter (4-12 mm) paper tube production, such as paper straw, pen tube. |
| 1. Machine adopts PLC control, all data can be display in the touch screen. |
| 2. Numerical control servo cutter device, high precision cutting. |
| 3. Automatically cut, automatically fall pipe, automatically change speed and revert. |
| 4. Round knife cutting, incision more smooth, performance more stable. |
| 5. With online multi-cut blades, no need secondary cutting, save labor and time. |
| 6. With two units heating system design instead of gluing system,environmental friendly |
| 7.With waste-playing function,and more working stable,and automatic changing material |
| 8.The final product by this machine can put aside with long time and without going mouldy,and help customers save dryer |
| 9. Machine adopts Flange for fix the mandrel. |
| 10.Machine supply of lubricant automatically. |
