Main parameter
| Model HD-520 | |
| Film roll width | 250–Max.520mm |
| Bag length | 80-350mm(L) |
| Front bag width | 80-150mm(W) |
| Side bag width | 35-90mm(W) |
| Width of edge seal | 5-10mm |
| Film thickness | 0.04-0.08mm |
| Packing speed | 10-40bag/min |
| Measuring range | 250-1000g |
| Power voltage | 220V/50Hz single/3 phase |
| Power | 4KW |
| Dimension | (L)1492mm× (w)1255mm× (H)2184mm |
| Machine weight | 980kg |
Characteristic
- Automatic weighing of products, production of bags, date printing, sealing and packaging are completed automatically at one time.
- Chinese and English touch screen display, intuitive and simple operation.
- PLC computer control system, the operation is more stable, and any parameters can be adjusted without stopping.
- Ten groups of parameters can be stored, and the replacement of varieties is more accurate.
- The servo motor is used to pull and touch, and the positioning is more accurate.
- Independent temperature control system, the accuracy can reach ±1℃.
- The horizontal and vertical sealing temperatures are independently controlled, which can be well applied to various composite films, PE films and other packaging materials.
- The styles of packaging are diversified, such as back sealing, gusset, four-side ironing, four-side sealing, standing bag, even bag, punching, etc.
- The working environment is clean and the noise is low.
Multi-heads details
- inch color multi-language (Chinese, English, Arabic, Spanish, etc.) touchscreen
- The perfect combination of high precision and high speed, the best combination is instantly selected from the rich weight combinations through computer calculation.
- The high-precision digital weighing sensor makes the measurement instantaneously realized, and the pattern bucket is rotated, which is more convenient for the blanking speed.
- Chinese/English and other languages Yejing display operating system.
- IP65 and other waterproof and dustproof design. All parts are made of stainless steel, clean and hygienic. Totally sealed design prevents material accumulation and easy cleaning
- According to the characteristics of the object to be measured, the opening and closing speed of the hopper door can be finely adjusted to prevent breaking and jamming.
- Powerful automatic data statistics function, record the total number of bags, pass rate and single bag error for each batch of production.
- Optional devices: pattern weighing hopper, collecting hopper, printing device, out-of-tolerance sorting device.
Head weighing details
| Model | 10-multi-head weigher |
| Weighing range | 250-1000g |
| Weighing accuracy range | ±1-2g |
| Maximum weighing speed | 5-60 Bags/Min |
| Hopper capacity | 2.5L |
| drive mode | Stepping motor |
| Operation interface | 10 inch touchscreen |
| Power voltage | 220V/1500W/50`60HZ/10A |
| Sensor | Germany HBM |
Main electric component
| Item | Product name | Standard configuration |
| 一． | Controlling part： | Original |
| 1. | Touchscreen | Schneider/France |
| 2. | PLC controller | Schneider/France |
| 3. | Servo drive&motor | Schneider/France |
| 4. | Temperature controller | Yatai/Shanghai |
| 6. | Color-coded fiber | Autonics/South Korea |
| 二． | Pneumatic part: | |
| 1. | Horizontal seal cylinder | AirTAC/Taiwan |
| 2. | vertical seal cylinder | AirTAC/Taiwan |
| 3. | film-feeding cylinder | AirTAC/Taiwan |
| 4. | cutter cylinder | AirTAC/Taiwan |
| 5. | electromagnetic valve | AirTAC/Taiwan |
| 6. | Triplet | AirTAC/Taiwan |
| 三． | Electric component | |
| 1. | Intermediate relay | Schneider/France |
| 2. | Solid state relay | Yangming/Taiwan |
| 四． | Switch part： | |
| 1. | Proximity switch | Schneider/France |
| 2. | Button switch | Schneider/France |
| 3. | leakage overcurrent switch | Schneider/France |
| 4. | Power switch (3.6A) | Minghao/Shenzhen |
| 五． | Power cord and wiring part： | |
| 1. | Aviation power plug | Kangpuxin/Shenzhen |
| 六． | Print date part: | |
| 1. | Coding machine | Guangdong |
